Our Injection Molding Services
Only Moulding
Do you have your own mold and want to ensure high quality part production?
​
​
Only Mould making
Do you have in-house injection moulding facility and want precision engineered moulds?
Product/Mould Design
Do you know that outsourcing design services is much cheaper than having an in-house design team?
Mould Modification
Plast Fab is known internationally to solve problems that are considered most challenging and sometimes unsolvable
Integrated Manufacturing
Experience end-to-end injection molding project management.
Just focus on marketing the product and leave the design manufacturing to us!
Our In-House Moulding Machines
85 Tons
Specs of 85 Ton machine- Company: Indomax Screw dia: 40mm Shot weight: 160gm PS Max Daylight: 550mm Open Stroke: 350mm Tie Bar distance: 350mm*350mm
125 Tons
Specs of 125 Ton machine- Company: Indomax Screw dia: 45mm Shot weight: 280gm PS Max Daylight: 750mm Open Stroke: 550mm Tie Bar distance: 400mm*400mm
180 Tons
Specs of 180 Ton machine- Company: Windsor Screw dia: 60mm Shot weight: 400gm PS Max Daylight: 800mm Open Stroke: 600mm Tie Bar distance: 450mm*450mm
380 Tons
Specs of 380 Ton machine- Company: Windsor Screw dia: 70mm Shot weight: 1136gm PS Max Daylight: 1450mm Open Stroke: 710mm Tie Bar distance: 740mm*740mm
500 Tons
Specs of 500 Ton machine- Company: Windsor Screw dia: 80mm Shot weight: 1746gm PS Max Daylight: 1640mm Open Stroke: 820mm Tie Bar distance: 825mm*825mm
We have expertise in...
Insert Moulding
Do you want metal components in your plastic part?
We can make it possible with insert moulding!
Over Moulding
Do you want two different polymers in a single component?
​
We can make it possible with overmoulding!
Injection Molding Polymers
PP
Polypropylene
PPCP
Polypropylene Copolymers
PA (Nylon)
Nylon 6, Nylon 6-6, Nylon 4-6, Nylon 12
ABS
Acrylonitrile Butadiene Styrene
PC
Polycarbonate
PBT
Polybutylene Terephthalate
CA
Cellulose Acetate
TPE
Thermoplastic Elastomer
TPU
Thermoplastic Polyurethane
POM (Delrin)
Polyoxymethylene
PET
Polyethylene Terephthalate
PPO
Polyphenylene Oxide
PPS
Polyphenylene Sulfide
Mold Mechanisms
01.
Multiple Cavity Molds
02.
Family Molds
03.
3- Plate Molds
04.
Hot Runner Molds
05.
Molds with working
(Sprung Core/ Splits/ Unscrewing, Lifters, Sliders)
